Recently, with high-speed cameras, USA KINO gave such pretty amazing shocks to the whole world, we not only unveiled bounce phenomenon of small droplet appeared on surface of super-hydrophobic lotus leaf, but also tested different bounce effect on surfaces with different hydrophilic angles. Our research will be a powerful tool for interfacial property characterization in the future.
More leading, more professional, more creative, more study on interfacial chemical, and more secrets revealed about drops and bubbles, please expecting...
USA KINO Industry CO. Ltd.
• Marketing in North America • Brand • R&D
|Company Name:||USA KINO Industry CO. Ltd.|
|ADD:||14 Tyler Street, 3rd floor, Somerville, Boston, MA 02143|
|TEL :||+1 857 3027458 , +1 857 3027459|
A strategic investment company of USA KINO In China :
Solon Tech (Shanghai) Co. Ltd., China
• Global marketing • Production • After-sale service
|Company Name:||Solon Tech (Shanghai) Co. Ltd.|
|ADD:||Building D1-3F, NO 479,ChunDong Road,Xin Zhuang Industrial Park Building, Shanghai, China, 201108|
|TEL:||+86 21 33582205 / 33582206|
|FAX：||+86 21 33582206-8005|
|Company Name:||KINO Japan|
|ADD:||713, Lions Station Plaza Hanzomon 154 Kojimachi, Chiyoda, Tokyo, JP, 102-0083|
World Standard & Chinese Cost
We know more about how to get reliable result for your measurement of contact angle, surface tension and interface tension which is Key Information of Nanoscale Object.
Leading in surface chemistry instrument:
2005: USA KINO first introduced blue color LED background light into contact angle meter to get sharper and clearer drop shape.
2005: USA KINO optimized spinning drop interface tensiometer with such technology as emovable and both-ends-fixed sample tube sampling mode (RBSM), full-self-sealed quartz glass tube (FSGT)，gas-thermal temperature control mode (GTCM)，and build-in heating system.
2005: USA KINO provide the user with a method name 3th generation Wilhelmy plate method for measuring dynamic contact angle and dynamic surface tension.
2005: USA KINO was the first company in the world who developed a multi-titled sample stage controlled by micrometer for levelling the surface of sample and provided rotating stage for measurement of roll-off angle and advancing/receding contact angle as stardard unit for contact angle meter.
2006: USA KINO adopted balance with resolution 10ug and update speed 92data/s made by METTLER TOLEDO
2006: USA KINO implemented such algorithms as double circle fitting method, curve ruler method, RealDrop method and Spline fitting method ahead of our peers.
2007: A new algorithm named as ADSA-RealDrop method was described for measurement of surface tension based on pendant drop method and contact angle based on sessile drop method.
2007: Such world’s leading technologies as parallel background background light and telecentric lens were first introduced and used at contact angle meter model C60 series. It is very useful technology for you to get sharper and clearer drop shape and will enhance the reliability and accuracy of measured result of contact angle and surface tension.
2008: ADSA-RealDrop method is optimize and can be used to measure contact angle of Non-axisymmetric drop shape.
2008: Spining drop tensiometer with contact angle meter was made by USA KINO.
2009: USA KINO first adopted function of "image editor" at drop shape analysis software CAST3.0 for contact angle meter.
2009: We developed a special photostudio for contact angle meter to avoid the influence of the ambient light.
2010: New generation of Wilhelmy plate method which can correcting contact angle and buoyancy based on Young-Laplace equation fitting.
2011: New generation of portable (mobile) contact angle meter with two prism (one for lens and another for background light). So, we can get more clean, clear and high contrast.
2011: New generation of interfacial rheometer based on osillator with close loop.
2012: USA KINO revealed bounce behavior of lotus leaf and different bounce behavior between hydrophobic and hydrophilic surface for the first time in the world.
2012: For the first time in the world, USA KINO measured contact angle of lotus leaf (Result is about 160° for fresh leaf and 155° for dry leaf) and contact angle of water strider's leg (155° for living body and about 60° for dead)
2012: We Introduced high speed and resolution camera with USB3.0 interface into contact angle meter model C60 series for the first time in the world. Speed of camera is 152.0 FPS with Resolution (h x v) 2048 x 1088. Max speed is can reach to 700FPS or higher.
2013: USA KINO provided videos at youtube for your reference. we have more than 100 videos about contact angle meter and surface tensiometer for your application or getting tips at how to operate your meter made by KINO.
2014: Surface tensiometer with multi function was provide from USA KINO. It can be used to measure surface tension, used as balance and density balance.
2014: USA KINO invented ultra high pressure (Max 100Mpa) and high temperature (200℃) spinning drop tensiometer for measure IFT under same condition as underground.
2014: We have successfully developed the intrinsic contact angle measuring device, which has realized the calculation and analysis of rolling angle with higher precision. We have introduced new technology into the functions of SL200K series and C60 series contact angle meters, and completed the technical upgrade.
2015: USA KINO invented contac angle meter with three syringe to measure contact angle of three drops at one image and SFE based on acid base method will be calculated realtime.
2015: New generation of interfacial rheometer based on osillator with close loop and it can be controlled temperature up to 200℃ or higher. Again, we are the world first company who provided a system based on PI (Physik Instrumente ) to get more reliable result of dynamic surface tension or interfacial rheology based on osillating drop method. Max frequency can reach to 200Hz. Using camera with speed about 500FPS, you can measure surface tension or interface tension based on ADSA-RealDrop method.
2015: USA KINO invented continuous dosing syringe pump with automatic refilling liquid system for contact angle meter.
2015: USA KINO invented 3D contact angle meter used a new sample stage for measuring contact angle of same drop from 360°
2015: USA KINO invented calculating 6 values of contact angles by three drop at one image to calculate surface free energy of solid by acid-base method. This method is very useful due to it can calculate realtime contact angle of the three drop by different liquid.
2015: New generation of oscillating drop method with ultra high speed system with max 100Hz or 200Hz oscillator.
2016: We exposed sandwich effect of surface tension from measuring surface tension of milk and developed a special method to measure the surface tension at both upper and lower layer of interface.We have applied a patent in China for this method and it's very useful for print, paint, wafer, milk, etc.
2016: We are the first one who use color camera for optical contact angle meter and spinning drop interface tensiometer. You can find the edge of drop shape by color camera and blue backgroud light.
2017: We invented the 3D contact angle lens for measuring contact angle. You can measure multiple contact angle from different side view angle at one image, calculate the values of contact angle for both of them.
2017: We applied TOF camera in the contact angle meter to measure 3D contact angle.
2017: We proposed ADSA-RealDrop is the real method for measuring contact angle. Other methods such as WH method, circle fitting, ellipse fitting (or double ellipse curve fitting method), tangent method using polynomial curve fitting method are goniometer method. Young-Laplace equation method is the entry level method for measure contact angle really due to Due to the correction of the gravity coefficient and calculating the contact angle and surface tension together. But Young-Laplace equation method can only be used for axisymmetric drop shape. The real drop shape of 98% surface of solid is nonaxisymmetric drop shape. So, only ADSA-RealDrop based on ADSA-P can be used calculate nonaxisymmetric drop shape.
2018: We developed a calibration tool which uses Ruby Ball instead of rod for spinning drop interface tensiomer.
2018: We're working on a whole new technology disruption.....
Comprehensive Solutions for your application at surface chemistry — KINO's Brand Vision
- As a world's technological pioneer in interfacial science, we are not only keeping pace with the change of new trends and technologies in measurement filed of surface tension, interfacial tension and contact angle, but build your customized interface science for you based on our professional technology and scientific advice.
- We built up confidence from good communication between our clients and KINO's professional engineer, our Legos-like system disign and our rich experience in measuring method of interface science.
- We are your first choice neighbourly parter in interface science. We can assist and build you customized meter of interface science by Instant Messaging at any time and anywhere around world.
- We have more than one hundred of video of contact angle meter, surface tensiometer and interface tensiometer to assist you at using meter from us and get more knowlege and skill in the repository from USA KINO. We promise you a most suitable solution for your measurement of contact angle or surface tension or interface tension of your special sample.
